SA-02	SA-01	SAF12C
	Waterproof, Dustproof, Insulated / Integrated cable	Low sensitivity / Integrated cable	Waterproof, Insulated / Integrated cable
	Waterproof and dustproof type standard vibration sensor. The insulated structure prevents leakage current from affecting the product.	Low sensitivity type vibration sensor.	Waterproof type standard vibration sensor for VM series. The insulated structure prevents leakage current from affecting the product.
Cable length	1.0 to 40.0m (Can be manufactured in 0.5m pitch)	1.0 to 40.0m (Can be manufactured in 0.5m pitch)	2.5m (Curled cord)
Voltage sensitivity	10mV/(m/s2) ±10%	5mV/(m/s2) ±10%	10mV/(m/s2) ±10%
Resonant frequency	Approx. 20kHz	Approx. 20kHz	Approx. 22kHz
Frequency range [*1]	fc to 5kHz ±1dB fc to 10kHz ±3dB	fc to 8kHz ±1dB fc to 12kHz ±3dB	6 to 3kHz ±1dB 3 to 6kHz ±3dB
Max. operating acceleration	10,000m/s2	16,000m/s2	350m/s2
Impact resistance	Over 10,000m/s2	Over 20,000m/s2	Over 5,000m/s2
Operating temperature	-40 to +80℃	-40 to +80℃	-20 to +120℃ (Up to 2mA) -20 to +110℃ (Up to 5mA)
Insulation resistance	Over 10,000MΩ	Over 10,000MΩ	Over 10,000MΩ
Max. lateral sensitivity	5% or less	5% or less	5% or less
Ground	Mounting surface insulation	Case	Double case insulation
Detection structure	Piezoelectricity & Compression	Piezoelectricity & Compression	Share
Protection level	Equivalent to IP57	-	IPX2
Dimension (mm)	Hex.17 × 74(H)	Φ15 × 65(H)	Hex.17 × 40(H)
Weights	40g (Without cable)	30g (Without cable)	55g (Without cable)
Case material	Stainless steel (SUS303)	Stainless steel (SUS303)	Stainless steel
Mounting screw	M6 × P1.0 (Male screw)	M6 × P1.0 (Female screw)	M6 × P1.0 (Female screw)
Accessory	-	M6 × P1.0 × 10mm Mounting screw	M6 × P1.0 × 10mm Mounting screw
Supported models	SB-7707RB, SB-8806RB, CM-3001, VM-1001, VM-2001	SB-7707RB, SB-8806RB, CM-3001, VM-1001, VM-2001	VM-1001, VM-2001

*1: "fc" is a value determined by the time constant with the amplifier.

	P12SC	S12C	S42SC
	General purpose	General purpose	Ultra high sensitivity
	Standard vibration sensor for a wide range of applications at a low price.	Low cost and a wide range of applications.	Even weak vibrations can be measured.
Charge sensitivity	10pC/(m/s2) ±10%	10pC/(m/s2) ±10%	35pC/(m/s2) ±10%
Resonant frequency	Approx. 23kHz	Approx. 25kHz	Approx. 14kHz
Frequency range(*)	fc to 5kHz ±1dB fc to 10kHz ±3dB	fc to 5kHz ±1dB fc to 7kHz ±3dB	fc to 3.5kHz ±1dB fc to 5kHz ±3dB
Max. operating acceleration	10,000m/s2	10,000m/s2	1,250m/s2
Impact resistance	10,000m/s2	15,000m/s2	2,500m/s2
Operating temperature	-20 to +140℃	-20 to +120℃	-20 to +120℃
Capacitance	1,000pF ±20%	1,000pF ±20%	1,500pF ±20%
Insulation resistance	Over 10,000MΩ	Over 10,000MΩ	Over 10,000MΩ
Max. lateral sensitivity	5% or less	5% or less	5% or less
Ground	Case	Case	Case
Detection structure	Piezoelectricity & Compression	Piezoelectricity & Compression	Piezoelectric & Share
Dimension (mm)	14(Hex) × 32(H)	14(Hex) × 31.5(H)	24(Hex) × 30(H)
Weights	Approx. 36g	Approx. 35g	Approx. 100g
Case material	Stainless steel (SUS303)	Stainless steel (SUS303)	Stainless steel (SUS303)
Connector	Miniature Connector 10-32UNF	Miniature Connector 10-32UNF	Miniature Connector 10-32UNF
Mounting screw	M6 × P1.0 (Female screw)	M6 × P1.0 (Female screw)	M6 × P1.0 (Female screw)
Accessory	M6 × P1.0 × 10mm Mounting screw	M6 × P1.0 × 10mm Mounting screw	M6 × P1.0 × 10mm Mounting screw
Supported models	SB-7707RB, SB-7705R, SB-8806RB, SB-8002R, SB-8002RB, SB-8001G, SB-8001GB, VM-2001 [*2], VM-1001 [*2]	SB-7707RB, SB-7705R, SB-8806RB, SB-8002R, SB-8002RB, SB-8001G, SB-8001GB, VM-2001 [*2], VM-1001 [*2]	SB-7707RB, SB-7705R, SB-8806RB, SB-8002R, SB-8002RB, SB-8001G, SB-8001GB, VM-2001 [*2], VM-1001 [*2]

	P51C	F12BC
	Wide-range	Waterproof
	Can measure large acceleration vibrations.	With the use of a dedicated cable, it is waterproof in accordance with JIS C 0920 IPX7.
Charge sensitivity	5pC/(m/s2) ±10%	10pC/(m/s2) ±10%
Resonant frequency	Approx. 32kHz	Approx. 35kHz
Frequency range(*)	fc to 8kHz ±1dB fc to 12kHz ±3dB	fc to 5kHz ±1dB -
Max. operating acceleration	16,000m/s2	10,000m/s2
Impact resistance	20,000m/s2	-
Operating temperature	-40 to +150℃	-20 to +80℃
Capacitance	1,000pF ±20%	4,000pF ±20%
Insulation resistance	Over 10,000MΩ	Over 10,000MΩ
Max. lateral sensitivity	5% or less	5% or less
Ground	Case	Insulation between case and signal
Detection structure	Piezoelectricity & Compression	Piezoelectricity & Compression
Dimension (mm)	14(Hex) × 25.5(H)	24(Hex) × 26(H)
Weights	Approx. 25g	Approx. 90g
Case material	Stainless steel (SUS303)	Stainless steel (SUS303)
Connector	Miniature Connector 10-32UNF	Waterproof and insulated connector (Z126)
Mounting screw	M6 × P1.0 (Female screw)	M6 × P1.0 (Male screw)
Accessory	M6 × P1.0 × 10mm Mounting screw	-
Supported models	SB-7707RB, SB-7705R, SB-8806RB, SB-8002R, SB-8002RB, SB-8001G, SB-8001GB, VM-2001 [*2], VM-1001 [*2]	SB-7707RB, SB-7705R, SB-8806RB, SB-8002R, SB-8002RB, SB-8001G, SB-8001GB, VM-2001 [*2], VM-1001 [*2]

*1: "fc" is a value determined by the time constant with the amplifier.

*2: A charge converter is required for use with VM-1001 and VM-2001.

*Acceleration sensors except SA-02, SA-01 and V10L are OEM products of Fuji Ceramics Co.

	RS171D
	Insulation Stud
	Electrically isolate the vibration sensor from the object to be measured. It is effective in preventing deterioration of measurement accuracy due to leakage current, etc. of the measurement target.
Dimension (mm)	Hex.17 × 14(H)
Weights	10g
Mounting screw	Vib. sensor side : M6 × P1.0 (Male screw) Meas. target side : M6 × P1.0 (Male screw)

	V10L
	Ultra low speed use only
	Optical displacement sensor with pendulum spring system. High signal-to-noise ratio in the low-frequency range enables high-precision vibration measurement with little noise. Vibration sensor that enables balancing in the low RPM range, which has been considered difficult until now. *Vibration values measured by this sensor are not traceable to national standards. Use only for balance measurement purposes.
Frequency range	1 to 4Hz
Detection axis	Single axle
Sensitivity	5mV/μm *Balancer setting sensitivity
Resolution	±0.001μm
Frequency response	3Hz ±1dB
Natural frequency	7.5Hz ±1.0Hz
Supply voltage	DC 3 to 5V 40mA or less
Operating temperature	0 to 40℃
Weights	Approx. 1.2kg
Dimension (mm)	50(W) × 78(D) × 97(H)
Supported models	SB-7707RB, SB-7705R, SB-8806RB *Low speed option must be installed

Vibration sensor fixing magnet

Vibration sensor cable (For Charge output type)

Rotation sensor

Rotation sensor fixed magnet

Reflection sticker
